CIARE FXI10.50W 12" 220watt 8ohm loudspeaker

Ideal for Hifi and Pa applications

Program Power 450 W
Rated Impendance 8 Ohm
Nominal Diameter 10''- 250 mm
Sensitivity 96 dB (2,83V/1m)
Voice Coil Diameter 2 in - 50 mm
Frequency Range 50-4500 Hz

Nominal Diameter 10''- 250 mm
Rated Impendance 8 Ohm
Nominal Power Handling 1 220 W
Program Power 450 W
Sensitivity 96 dB (2,83V/1m)
Frequency Range 50-4500 Hz
Frame Material Aluminium
Magnet Material Ferrite
Cone Material Paper Cellulose
Cone Shape Exponential
Surround Nomex
Suspension Nomex
Voice Coil Diameter 2 in - 50 mm
Voice Coil Winding Material Aluminium
Voice Coil Length 12.7 mm - 0,5 in
Voice Coil Former Material Aluminium
Ferrofluid No
Magnet Gap Height 8 mm - 0,31 in
Efficiency Bandwidth Product EBP 112

T/S Parameters
Resonance Frequency 58 Hz
DC Resistance 5,8 Ohm
Mechanical Q Factor 4.3
Electrical Q Factor 0.41
Total Q Factor 0.38
BI Factor 13,3 Tm
Effective Moving Mass 34.5 g
Equivalent Cas air Loaded 38.5 lt (dm³) - 1.36 cuft
Effective Piston Diameter 213 mm - 8,39 in
Effective Piston Area 356 cm² - 55.18 sq in
Max. Linear Excursion 4.5 mm - 0,18 in
Voice Coil Inductance @ 1kHz 0,85 mH
Half.space Efficiency 2,7 %

Dimension and weight
Overall Diameter 268 mm - 10.55 in
Baffle Cutout Diameter 235 mm - 9.25 in
Flange and Gasket Thickness 13 mm - 0,51 in
Total Depth 111 mm - 4.37 in
Bolt Circle Diameter 253 mm - 9.96 in
Bolt Holes Quantity and Diameter 8 / 7 mm - 0,28 in
Net Weight 3,4 Kg - 7,49 lb

Designed & manufactured in Italy.

Model: FXI10.50W

note: Price includes VAT
